     Product Name:   T10 LED Tube light factory price,8ft,36w



LED Tubes light factory\manufactuer\supplier\price-T10

 Aluminum heat sink, No UV, IR or RF interference, Patented heat sink and optical diffuser, longer life than incandescent & fluorescent tube. No ballast required, universal voltage and constant current design, solid state, high shock & vibration resistant, Mercury free, 70%+savings in energy consumption, quiet, no noise, no flickering.The products are in accordance with CE, RoHS, UL and FCC testing standards.
 Color Temperature: Warm White:2600-3700K
                               Natural White:4000-4800k
                               Daylight White:5000-6500k
                               COOL White:6500-7500k
LED Tubes light factory\manufactuer\supplier\price-T10
Features:
1. Perfect frosted cover, up to 95% light transmittance.
2. Inner Aluminum Pipe+ PC Cover??/span>
3. 600/900/1200/1500/1800/2400mm is available.
4. Dimmable or Auto-dimmable function is available??/span>
5. No need to remove the tranditional ballast and starter.
6. Replace T8/T10/T12 fluorescent lamps.
7. Bi-pin, R17D, Single pin is available.
Description??/span>
SMD LED Tube light, Metal or Plastic end caps.
Specification:
 Type No.
Length
Dia.
LED Qty
Watt
LED Type
Lumen
LT-T10-8W
600mm
30mm
108pcs
8W
SMD 3528
800 lm±10%
LT-T10-12W
900mm
30mm
180pcs
12W
SMD 3528
1200 lm±10%
LT-T10-20W
1200mm
30mm
324pcs
20W
SMD 3528
2000 lm±10%
LT-T10-24W
1500mm
30mm
360pcs
24W
SMD 3528
2400 lm±10%
LT-T10-28W
1800mm
30mm
432pcs
28W
SMD 3528
2800 lm±10%
LT-T10-36W
2400mm
30mm
576pcs
36W
SMD 3528
3600 lm±10%
















LED Tubes factory\manufactuer\supplier\price-T10
Electrical Parameters:
Input Voltage:85-277VAC or 12-36VDC
Frenquency: 50/60Hz
Power factor: 0.95~0.98

Optical Parameters:
Light Efficiency: 100Lm/w
Color Temperature: Warm white, Pure white, Cool white

Other Parameters:
Porduct Patents: Yes
Operating Temperature: -20??45??
Appearance: Transparent/frosted /Stripe
Main Material: Aluminum + PC cove
IP Rating: IP40
CRI: 80Ra
Life Span: >50,000 hours

Certificates:
CE, RoHS, FCC

Lux Report (Pure White)

Type No.
Height: 1m
Height: 2m
Height: 3m
LT-T10-8W
138±10Lux
50±10Lux
35±10Lux
LT-T10-20W
257±20Lux
90±20Lux
48±20Lux
LT-T10-24W
273±20Lux
102±20Lux
55±20Lux
LT-T10-36W
455±20Lux
195±20Lux
110±20Lux










Product Features:
Low Lumen Decline. Almost "Zero" after 3000 hours.
Life: >50.000 hours.
Save more than 70% energy.
Brighter than traditional fluorescent lamps.

Applications:
Houses, offices, exhibitions, meeting rooms, hotels, restaurants, schools, factories, hospitals, workshops, warehouses, underground car parks, etc.


Caution:
1. LED tube and its all fittings cannot withstand any mechanical pressure.
2. Any question about the installation of our LED tubes, please ask for professional guide.
3. If the aluminum pipe is damaged or deformed, please stop using the LED tube to avoid dangers.
4. Before installation, please switch off the electricity, and ensure to install our led tube normally.
5. Please install or place the LED tubes to avoid sunlight and high temperature.
6. It is only used indoors.
